Yamaha S3115H Speaker System Owner's Manual

About this manual

The Yamaha S3115H is a bass reflex type speaker system featuring a 38 cm woofer (JA3803) and an HF Driver & Horn (JA4204A). It has a system impedance of 8 ohms and a power handling capacity of 100W continuous program. The manual includes instructions for connecting the unit to PA mixers or external amplifiers, as well as guidance on parallel connections.

What's inside

• Specifications
• Precautions for Use
• Connection
• Panel Operation
• Frequency Response

Specifications

Frequently asked questions

What is the maximum number of S3115H systems that can be connected in parallel?

Do not connect more than two speaker systems in parallel unless using a power amplifier which operates stably with a load impedance of below 4 ohms.

What type of input terminals are used for the Parallel Input?

The Parallel Input uses phone jack type input terminals.
