The PW3000MA power supply is a 3000W audio power amplifier that can provide power for YAMAHA's mixers. It has 4 types of power outputs, which can be checked through the operation monitor on the front panel.
The Yamaha PW3000MA is a power supply designed to support various mixing consoles. It features an ON/OFF switch, LED status indicators, grounding terminals, and DC parallel input capabilities to allow two units to operate in parallel for increased capacity or redundancy.
This document covers safety precautions regarding installation and operation, describes the front and rear panel controls including the OPERATION MONITOR LEDs, details the pinout for DC output connections, and lists compatible mixing console models. This manual is written in Japanese.
| Power Requirement | 220V, 50Hz |
|---|---|
| Power Consumption | 500W |
| Dimensions (W x H x D) | 480mm X 103.5mm X 455mm |
| Weight | 15kg |
If an LED indicator for a specific power section becomes dim, it indicates a fault. You should turn off the power supply and wait before turning it back on.
Yes, the DC Parallel Input connector allows two PW3000MA units to operate in parallel. In this mode, they output 50% power each.
The PW3000MA is compatible with models including the M2500-56C, M3000A-56C, M2500-48C, and others listed in the manual.
