This application guide introduces the applications of the Yamaha 02R and 03D digital mixing consoles.
This Applications Guide provides detailed examples of real-life 02R and 03D recording systems. The application diagrams show exactly what equipment is needed for each system and how to connect and make the relevant settings. The 02R and 03D feature as the main components throughout the applications, with various equipment by other manufacturers introduced to form complete systems.
The guide covers two main parts: Part 1 focuses on 02R Applications, detailing connections with devices like Akai DR8/DR16, Alesis ADAT, Fostex D-90/RD-8, TASCAM DA-88, and Pro Tools. Part 2 covers 03D Applications, including setups with Akai, Fostex, TASCAM, and Midiman Syncman Plus, as well as basic MIDI studio configurations and installation instructions.
The Alesis ADAT Professional Digital Audio Recorder features a sampling rate of 48 kHz.
The Fostex RD-8 Digital Multitrack Recorder features 100 locate points.
A 120 minute tape provides a recording time of 108 minutes for the TASCAM DA-88.
