HCTS299MS is an 8-bit universal shift register with three-state function produced by Intersil. The product uses a 3-micron radiation-hardened CMOS SOS process, with a total dose of 200K RAD (Si), an SEP effective LET no upsets of >100 MEV-cm2/mg, a < 2 x 10-9 errors/bit day (typical) single event upset (SEU) immunity, a >1 x 1012 RAD (Si)/s dose rate survival capability, and a >1010 RAD (Si)/s 20ns pulse dose rate upset. The product is free from latch-up under any conditions and supports 15 LSTTL load bus driver outputs.
The Intersil HCTS299MS is a radiation-hardened 8-bit shift/storage register featuring a three-state bus interface. It utilizes advanced CMOS/SOS technology to achieve high-speed operation and is compatible with TTL input levels. The device is designed for military temperature ranges from -55°C to +125°C.
| Total Dose | 200K RAD (Si) |
|---|---|
| Single Event Upset Immunity | < 2 x 10^-6 Errors/Bit-Day (Typ) |
| Operating Temperature Range | -55°C to +125°C |
| DC Operating Voltage Range | 4.5V to 5.5V |
| Package Type | 20 Lead Ceramic Dual-In-Line (SBDIP) |
The device has a total dose rating of 200K RAD (Si).
The device operates with a DC supply voltage between +4.5V and +5.5V.
The device functions within a military temperature range of -55°C to +125°C.
