PowerPC 405CR is a 32-bit RISC embedded controller produced by AMCC. This controller has the characteristics of high performance, peripheral integration, and low cost, making it ideal for embedded applications.
The AMCC PPC405CR is a 32-bit RISC embedded controller featuring a PowerPC 405 processor core operating up to 266 MHz. It includes a Memory Management Unit, 16KB instruction and 8KB data caches, and a Multiply-Accumulate function. The device is designed for wired communications, network printers, and other computing applications, offering high performance with low cost.
| Processor Core | PowerPC 405 32-bit RISC processor core |
|---|---|
| Operating Frequency | up to 266MHz |
| Instruction Cache | 16KB |
| Data Cache | 8KB |
| SDRAM Interface Frequency | up to 133 MHz |
| Technology | CMOS SA-12E 0.25 um |
| Package Type | 27mm, 316-ball enhanced plastic ball grid array (E-PBGA) |
| Typical Power | 0.8W |
| Maximum Power | 2.0W at 200 MHz |
| Serial Ports | Two |
The processor core operates up to 266 MHz.
It uses a 27mm, 316-ball enhanced plastic ball grid array (E-PBGA).
Yes, it supports ECC applications via a 40-bit interface.
