This document introduces the features and characteristics of the ADM1073 hot swap controller
The ADM1073 is a full-feature, negative voltage hot swap controller designed to allow boards to be safely inserted into and removed from a live -48 V backplane. It provides precise inrush current limiting by controlling the gate drive of an external N-channel FET, protecting against both transient and nontransient short circuits.
| Operating Supply Voltage Range (Vin Pin) | -18 V to -200 V |
|---|---|
| Typical Operating Voltage Range | -35 V to -80 V |
| Package Type | 14-lead TSSOP |
The device can operate from a negative voltage of -18 V to -80 V and tolerate transient voltages up to -200V.
The device can operate from a negative voltage of -18 V to -80 V.
The part can tolerate transient voltages of up to -200 V.
