Agilent 6890 Accessory Install Sheets-PP guide

About this manual

This document provides step-by-step instructions for installing a purged packed inlet with electronic pneumatics control (EPC) into an Agilent 6890 Gas Chromatograph. It includes safety warnings, a list of required parts and tools, and the specific procedure to prepare the instrument chassis.

What's inside

• Overview
• Safety Information
• Parts List
• Required Tools
• Preparing the GC
• Installing the bottom cover plate
• Installing the flow manifold
• Installing the inlet
• Restoring the GC to operating condition
• Calibrating your inlet

Frequently asked questions

What safety precaution is required before removing the GC side panels?

You must unplug the power cord to avoid a potentially dangerous shock hazard.

Which screwdriver is required to remove the inlet cover plate?

You need a T-20 Torx screwdriver to loosen the two screws holding the plate.

How many captive screws secure the injection port cover?

There are five captive screws that must be loosened to lift off the cover.
