The PD55015 is a high gain, broad band commercial and industrial application N-Channel enhancement-mode lateral Field-Effect RF power transistor. It operates at 12V in common source mode at frequencies of up to 1GHz. PD55015 boasts the excellent gain, linearity and reliability of ST’s latest LDMOS technology mounted in the first true SMD plastic RF power package, PowerSO-10RF. PD55015’s superior linearity performance makes it an ideal solution for car mobile radio. The PowerSO-10 plastic package, designed to offer high reliability, is the first ST JEDEC approved, high power SMD package. It has been specially optimized for RF needs and offers excellent RF performances and ease of assembly.
File format: PDF
Size: -
MD5 Checksum: A5B6875C454EDA019A1339E9CFB70522
Publication date: 07 June, 2012
Downloads: -
PDF Link: ST PD55015 - PD55015S handbook PDF
