The AD712 is a high-speed, precision monolithic operational amplifier offering high gain, low cost, high speed, and bi-directional enhancement.
The AD712 is a high-speed, precision monolithic operational amplifier designed to offer excellent performance at competitive prices. It utilizes advanced laser wafer trimming technology to achieve very low offset voltage and drift, making it suitable for upgrading existing designs based on older BiFET or bipolar op amps.
Key features include a minimum slew rate of 16 V/µs and a settling time of 1 µs to ±0.01%, which makes the device ideal as a buffer for 12-bit D/A and A/D converters. The amplifier is available in various performance grades covering commercial, industrial, and military temperature ranges.
| Unity Gain Bandwidth (Min) | 3 MHz |
|---|---|
| Offset Voltage (Max, C Grade) | 0.3 mV |
| Common-Mode Rejection Ratio (Typical) | 88 dB |
The device is available in commercial (0°C to +70 °C), industrial (-40 °C to +85 °C), and military (-55 °C to +125 °C) grades.
Yes, with a settling time of 1 µs and low input current, it is ideal as a buffer for 12-bit D/A and A/D Converters.
