The Agilent T7111 ATC Probe is a temperature probe designed for measuring temperature with the Agilent 3200 series meters. It has a temperature range of 0-100°C with an accuracy of ±0.3°C (0-60°C) and ±1.0°C (60-100°C). The probe features a stainless steel measuring tip with a diameter of 4mm and a length of 120mm. To use the probe, it should be immersed in the sample solution with a depth of at least 10mm, and the stable reading should be recorded. Avoid applying force to the probe cap, cable, or cable interface, and keep the cable interface dry. For any troubleshooting during probe use, contact Agilent Technologies customer service. Store the probe in a storage box at ambient temperature and dry conditions.
The Agilent T7111 is a laboratory-grade ATC (Automatic Temperature Control) probe designed with a stainless steel measuring tip. It is intended for use with the Agilent 3200 series of meters to measure temperature in sample solutions within a range of 0 to 100 °C.
The guide provides instructions on proper operation, including connecting the miniDIN4 interface cable and ensuring the probe tip is submerged at least 10 mm deep. It also outlines storage requirements, such as keeping the device dry and avoiding force on the cap or cable.
| Temperature range | 0 to 100 °C |
|---|---|
| Accuracy (0–60 °C) | ±0.3 °C |
| Accuracy (60–100 °C) | ±1.0 °C |
| Body material | Stainless Steel |
| Cable interface | miniDIN4 |
| Probe diameter | 4 mm |
| Probe length | 120 mm |
| Cable length | 1000 mm |
The probe should be used with the Agilent 3200 series of meters.
The depth into the sample solution must be at least 10 mm.
