This document introduces the LTC2195 family, a low power 16-bit high speed signal chain solution, which is ideal for applications that require 16-bit performance and ultralow power consumption to extend battery life, such as portable medical imaging equipment.
The article discusses the LTC2195 family of 16-bit, high-speed analog-to-digital converters (ADCs), highlighting their ultralow power consumption suitable for portable sampling systems. It details a signal path design using the LTC6406 amplifier to condition image sensor signals before sampling by the ADC.
The nominal common mode voltage is 0.9V.
The cutoff frequency is 12MHz.
