This document is a standard microcircuit drawing for a 90-volt synchro to digital converter. The product features linear characteristics and hybrid technology. The document also provides revisions to the testing notes and drawing requirements.
This document is a revision of a Department of Defense drawing (DSCC Form 2233) for the 5962-92054 hybrid linear microcircuit. It serves as a specification sheet defining five product assurance classes, device types ranging from 14-bit to 16-bit converters, and various case outlines and lead finishes.
The datasheet details absolute maximum ratings, recommended operating conditions, electrical performance characteristics including resolution and accuracy, and quality assurance provisions such as burn-in testing requirements in accordance with MIL-STD-883.
Device types 05 through 12 have a minimum resolution of 16 bits.
