DTB114GK is a digital transistor from Nexperia that features built-in resistors, allowing for positive biasing of the input and almost complete elimination of parasitic effects. The transistor is suitable for applications such as inverters, interfaces, and drivers.
The DTB1 14GK transistor features an integrated thin‑film resistor that provides complete isolation and allows positive biasing of the input, greatly reducing parasitic effects. Its structure is a PNP epitaxial planar silicon device and it is supplied in an SMT3 surface‑mount package, enabling higher mounting densities.
Electrical characteristics include a collector‑emitter breakdown voltage of 50 V, a maximum collector current of 500 mA, a typical built‑in resistor value of 10 kΩ, and a transition frequency of 100 MHz. Absolute maximum ratings and detailed characteristic curves are provided for various temperature conditions.
| Built‑in resistor value | 10 kΩ (typ.) |
|---|---|
| Transition frequency (fT) | 100 MHz |
The built‑in resistor is typically 10 kΩ.
