This manual is intended for administrators and users of the AXIS 209FD/FD-R Network Camera, and is applicable for software release 4.47 and later. It includes instructions for using and managing the camera on your network. Previous experience of networking will be of use when using this product. Some knowledge of UNIX or Linux-based systems may also be beneficial, for developing shell scripts and applications. Later versions of this document will be posted to the Axis Website, as required. See also the product’s online help, available via the Web-based interface. Safety Notices Used In This Manual Caution! - Indicates a potential hazard that can damage the product. Important! - Indicates a hazard that can seriously impair operation. Do not proceed beyond any of the above notices until you have fully understood the implications.
The Axis 209FD/FD-R/FD-R M12 is a high‑performance fixed dome network camera designed for indoor office use and ruggedized for humid, in‑vehicle environments. It offers up to 30 fps VGA video, Power over Ethernet, and advanced security features such as multi‑level password protection and HTTPS encryption.
This manual covers installation, initial access, configuration of network and video settings, security options, event handling, and detailed technical specifications. It also explains how to use the AXIS Media Control, stream MPEG‑4 or Motion JPEG video, and perform maintenance tasks.
| Image sensor | 1/4" Micron Progressive Scan RGB VGA CMOS |
|---|---|
| Lens | 3.0 mm, F2.0, fixed iris |
| Angle of view | 66° horizontal |
| Illumination | 1.5–10 000 lux, F2.0 |
| Video compression | Motion JPEG, MPEG‑4 Part 2 |
| Frame rate | Up to 30 fps at all resolutions |
| Power | Power over Ethernet IEEE 802.3af, Class 1 |
| Operating temperature (209FD) | 0 °C to 50 °C |
It can be powered via Power over Ethernet (PoE) complying with IEEE 802.3af Class 1.
Up to 20 simultaneous users are supported, with unlimited users possible when using multicast streams.
