MT9P031 is a 1/2.5-inch 5-Mp digital image sensor that incorporates sophisticated camera functions such as windowing, binning, column and row skip mode, and snapshot mode. It is program-mable through a simple two-wire serial interface. The MT9P031 produces extraordinarily clear, sharp digital pictures, and its ability to capture both continuous video and single frames makes it the perfect choice for a wide range of consumer and commercial security applications, including high resolution network cameras; pan, tilt, and zoom cameras; and hybrid video/still cameras.
The MT9P031 is a 1/2.5‑inch CMOS digital image sensor featuring a 2592 × 1944 active‑pixel array and a variety of camera functions such as windowing, binning, row/column skip and snapshot modes. It is intended for consumer and commercial security applications, including high‑resolution network, pan‑tilt‑zoom and hybrid video/still cameras.
The sensor is programmed via a simple two‑wire serial bus and provides a 12‑bit on‑chip ADC, up to 96 Mp/s pixel rate, and configurable frame rates up to 14 fps at full resolution. It operates from 1.7‑1.9 V core digital supply, supports multiple power modes, and is packaged in a 48‑pin iLCC module.
| Active pixel array | 2592 × 1944 |
|---|---|
| Pixel size | 2.2 µm × 2.2 µm |
| Maximum frame rate (full resolution) | 14 fps |
| ADC resolution | 12‑bit |
| Core digital supply voltage | 1.7 V – 1.9 V |
| Power consumption (full resolution, 14 fps) | 381 mW |
| Operating temperature range | ‑30 °C to +70 °C |
| Package type | 48‑Pin iLCC |
It is programmable through a simple two‑wire serial interface.
The maximum pixel rate is 96 megapixels per second.
Core digital 1.7‑1.9 V, I/O 1.7‑3.1 V, analog 2.6‑3.1 V, pixel supply 2.6‑3.1 V.
