The Dell OptiPlex 980 Service Manual provides a comprehensive overview of the Mini Tower, Desktop, and Small Form Factor versions of the computer. It details marketing system configurations, supported operating systems, chipset information, and advanced manageability features.
The guide also includes detailed engineering specifications such as physical dimensions, weight, connector layouts, audio and communication interfaces, and acoustic noise emission data. Service technicians can use the connector diagrams and jumper settings to diagnose and repair the system. This manual is written in Chinese.
| Height (Mini Tower) | 15.8 in / 40.8 cm |
|---|---|
| Width (Mini Tower) | 7.4 in / 18.7 cm |
| Depth (Mini Tower) | 17.2 in / 43.3 cm |
| Chassis Weight (Mini Tower) | 25.3 lb / 11.6 kg |
| Chipset | Intel Q57 Express |
The OptiPlex 980 is built on the Intel Q57 Express chipset.
