AD73322L is a low-cost, low-power CMOS general-purpose dual analog front end.
The AD73322L is a low‑cost, low‑power CMOS dual analog front‑end featuring two 16‑bit A/D converters and two 16‑bit D/A converters. It provides 78 dB signal‑to‑noise ratio for both ADC and DAC paths and supports programmable input/output sample rates up to 64 kHz.
The device operates from a single 2.7 V‑3.3 V supply, consumes about 50 mW at 3.0 V, and works over an industrial temperature range of –40 °C to +105 °C. Pin configurations, timing diagrams, absolute maximum ratings and ordering information are included for designers.
| A/D converters | Two 16‑bit |
|---|---|
| D/A converters | Two 16‑bit |
| ADC SNR | 78 dB |
| DAC SNR | 78 dB |
| Maximum sample rate | 64 kHz |
| Supply voltage | 2.7 V to 3.3 V (single‑supply) |
| Power consumption | 50 mW typ at 3.0 V |
The device supports a maximum sample rate of 64 kHz.
Typical power consumption is 50 mW at a 3.0 V supply.
Both the ADC and DAC have a signal‑to‑noise ratio of 78 dB.
