This document is about N series connectors. It introduces the interface, characteristics, straight plugs and straight jacks of N series connectors.
The N Series coaxial connectors are designed for telecommunications, military, and industrial applications, offering a wide range of models with optimized part‑design, full‑crimp and clamp attachment options, and high‑performance non‑magnetic plating. The series includes straight and right‑angle plugs, straight and bulkhead jacks, flange‑mount and bulkhead‑mount options, as well as a complete COAXI‑KIT of heads and tips.
The document contains detailed interface dimensions, electrical and mechanical characteristics, a comprehensive finder guide, part‑number indexes, accessory listings, and cable‑assembly information. It also provides recommended torque values, environmental test data, and cross‑references for all N‑series components.
| Impedance | 50 Ω |
|---|---|
| Frequency range | DC‑11 GHz |
| Recommended coupling nut torque | 40‑60 Ncm (manual) |
The connectors have a characteristic impedance of 50 Ω.
The series operates up to 11 GHz.
The recommended torque is 40 to 60 Ncm when tightened manually.
