ViewSonic's PJ1173 is a high-brightness multimedia projector ideal for large venue presentations. It features 5000 lumens, 1000:1 contrast ratio, support for 1080p signals, network control, and enhanced security features.
The PJ1173 is a high‑brightness XGA multimedia projector designed for large‑venue presentations such as conference rooms, lecture halls, and boardrooms. It offers 5,000 ANSI lumens brightness, 1000:1 contrast ratio, manual lens shift, auto keystone correction, and built‑in 4 × 4 W SRS® WOW stereo speakers.
The manual covers installation, network control via RJ‑45, security features like PIN lock and a Kensington lock, audio/video input options, and warranty information. Detailed technical specifications, connector types, and optional accessories are also listed.
| Brightness | 5,000 ANSI lumens |
|---|---|
| Contrast Ratio | 1000:1 |
| Resolution | 1024 × 768 (XGA) |
| Lamp Power | 275 W |
| Throw Ratio | 1.5 ~ 1.8:1 |
| Power Consumption | 460 W (typ) |
| Noise Level (Normal) | 39 dB (typ) |
| Weight (Net) | 15.8 lb (7.1 kg) |
| Dimensions | 418 mm × 139 mm × 319 mm |
The PJ1173 provides 5,000 ANSI lumens of brightness.
Remote control is possible via the RJ‑45 network connector, allowing scheduling, monitoring, and email alerts.
The projector includes a PIN lock, Kensington security lock, and a security bar to deter theft.
It has four 4‑watt speakers with SRS® WOW technology for stereo sound.
