The PJD7383i is an Epson interactive short throw projector with XGA resolution, 120Hz refresh rate, and 3D support. It has a short throw lens and supports real-time monitoring and control, and can project out an 81-inch screen.
The PJD7383i is an interactive short‑throw DLP® projector that delivers 3000 lumens, 1024×768 XGA native resolution, and BrilliantColor™ technology for vivid color reproduction. It supports 120 Hz refresh rates, 3D content, and includes an interactive pen for classroom use.
The manual covers hardware specifications, connector options, control functions, optional accessories, and step‑by‑step setup procedures. It also lists power‑saving features such as Eco‑mode lamp life extension and network management via RJ‑45.
| Resolution | 1024x768 (XGA native) |
|---|---|
| Brightness | 3000 Lumens |
| Contrast Ratio | 2000:1 static, 3000:1 dynamic |
| Throw Ratio | 0.61:1 |
| Lamp Life (Eco‑mode) | up to 6,000 hours |
| Power Consumption | 298 W typical, 1 W standby |
| RGB Input Connector | 15‑pin mini D‑sub |
| Control Interface | RS‑232 (9‑pin mini‑DIN) / RJ‑45 |
| Optional Replacement Lamp | RLC‑0S7 |
| Optional Short Throw Mount | WMK‑027 |
The lamp life in Eco‑mode is up to 6,000 hours.
The projector has a throw ratio of 0.61:1.
The projector delivers 3000 lumens of brightness.
