EL2074C is a precision voltage-feedback amplifier from Elantec Semiconductor with a 400MHz gain-bandwidth product, fast settling time, excellent differential gain and differential phase performance, and a minimum of 50mA output current drive over temperature.
The EL2074C is a high‑performance, voltage‑feedback operational amplifier from Elantec Semiconductor. It offers a 400 MHz gain‑bandwidth product, 50 mA output current, and low input offset voltage (200 µV) suitable for high‑speed video, active filters, and precision signal‑processing applications.
The datasheet provides absolute maximum ratings, detailed DC and AC electrical characteristics, typical performance curves, and application notes such as parasitic capacitance handling and video distortion measurements.
| Gain‑Bandwidth Product | 400 MHz |
|---|---|
| Gain‑of‑2 Stability | Yes |
| Output Current (short‑circuit) | 50 mA |
| Input Offset Voltage | 200 µV |
| Input Bias Current | 2 µA |
| Input Offset Current | 0.1 µA |
| Slew Rate | 275‑400 V/µs |
| Supply Voltage (Absolute Max) | 47 V |
The EL2074C has a gain‑bandwidth product of 400 MHz.
The device can deliver up to 50 mA of output current over temperature.
The input offset voltage is specified as 200 µV.
Yes, the amplifier is gain‑of‑2 stable.
