A63L0636 is a 1M×36 bit synchronous high-speed SRAM with preliminary burst counter and pipelined data output. Its features include fast access times, single +3.3V±10% or +3.3V-5% power supply, synchronous burst function, individual byte write control and global write, registered output for pipelined applications, etc.
The AMIC A63L0636 is a 1 M × 36 bit synchronous SRAM offering fast access times from 2.6 ns to 4.2 ns and a programmable burst counter. It features individual byte‑write control, global write, three chip‑enable pins, and a sleep mode, making it suitable for a wide range of high‑performance memory applications.
The device is supplied in a 100‑pin LQFP package and operates from a single 3.3 V supply (3.1 V – 3.6 V). Absolute maximum ratings include a supply voltage range of –0.5 V to +4.6 V and an operating temperature range of –0 °C to 70 °C.
| Access Time (ns) | 2.6, 2.8, 3.2, 3.5, 3.8, 4.2 |
|---|---|
| Supply Voltage (VCC) | 3.1 V – 3.6 V |
| Package | 100‑pin LQFP |
| Operating Temperature | -0 °C to 70 °C |
| Power‑Down Mode (ZZ) | Active‑high sleep, low wake‑up |
The device provides access times of 2.6 ns, 2.8 ns, 3.2 ns, 3.5 ns, 3.8 ns and 4.2 ns.
The recommended operating supply voltage is 3.3 V ± 10 % (typical 3.3 V, minimum 3.1 V, maximum 3.6 V).
It is supplied in a 100‑pin LQFP (Lead‑Quad Flat Package).
The device is rated for operation from –0 °C up to 70 °C.
