LT6011/LT6012 is a low noise, high precision input performance, low power consumption, rail to rail output swing precision operational amplifier. Input offset voltage can be trimmed to less than 60μV. Low drift and excellent long-term stability guarantee high accuracy over temperature and time. The maximum input bias current of 300pA and the minimum voltage gain of 120dB further maintain this precision over operating conditions. LT6011/LT6012 can operate at any power supply voltage from 2.7V to 36V and draw only 135μA of supply current on a 5V supply. The output swings to within 40mV of either supply rail, making the amplifier a good choice for low voltage single supply applications. LT6011/LT6012 are specified at 5V and ±15V supplies and from -40°C to 85°C. LT6011 (dual) is available in SO-8, MS8 and space saving 3mm x 3mm DFN package.
The LT6011 (dual) and LT6012 (quad) are low‑power precision operational amplifiers with rail‑to‑rail output swing. They combine low noise, low offset voltage, and low bias current, making them suitable for thermocouple, photodiode, and battery‑powered precision systems.
The document lists absolute maximum ratings, detailed electrical characteristics, typical performance graphs, and package dimensions for the DFN, SO, and SSOP options. It also includes ordering information and related part numbers.
| Maximum Input Offset Voltage | 60 µV |
|---|---|
| Maximum Input Bias Current | 300 pA |
| Supply Current per Amplifier | 135 µA |
| Supply Voltage Range | 2.7 V to 36 V |
| Operating Temperature Range | –40 °C to 85 °C |
| Gain Bandwidth Product (GBW) | 330 kHz |
| Maximum Output Swing (no load, 50 mV overdrive) | 55 mV |
| Package Type (LT6012) | 16‑Lead Plastic SSOP |
The devices operate from 2.7 V up to 36 V supply voltage.
The maximum input bias current is 300 pA.
The gain‑bandwidth product is typically up to 330 kHz.
They are specified for operation from –40 °C to 85 °C.
