The AD9608 is a 10-bit, 125/105 MSPS, 1.8 V dual-channel analog-to-digital converter (ADC) that delivers low power, high dynamic range (SNR), wide bandwidth (BW), and high precision (DNL) performance.
The AD9608 is a monolithic dual‑channel 10‑bit ADC from Analog Devices that operates at up to 125 MS/s with a 1.8 V supply. It offers low power (≈125 mW), on‑chip voltage reference, programmable clock and data alignment, and selectable CMOS or LVDS output drivers.
Typical applications include communications, handheld instruments, medical imaging and portable scopes. The device is supplied in a 64‑lead RoHS‑compliant LFCSP package and is rated for –40 °C to +85 °C operation.
| Maximum Sample Rate | 125 MSPS |
|---|---|
| Supply Voltage (AVDD) | 1.8 V |
| Typical Power Consumption (DC Input) | 125 mW |
| Signal‑to‑Noise Ratio | 61.7 dBFS at 70 MHz |
It operates from a single 1.8 V analog power supply and a separate 1.8 V digital output driver supply.
Typical DC input power consumption is about 125 mW.
