The L4970A is a 10A step-down monolithic power switching regulator that delivers 10A at a voltage that can vary from 5.1 to 40V. It has BCD mixed technology and uses a DMOS output transistor to achieve very high efficiency and very fast switching times. The L4970A has features such as reset and power fail for microprocessors, feed forward line regulation, soft start, limiting current and thermal protection. The device is mounted in a 15-lead multiwatt plastic power package and requires few external components. Its efficient operation at frequencies of up to 500KHz reduces the size and cost of external filter components.
The L4970A is a monolithic step‑down switching regulator that delivers up to 10 A with an adjustable output voltage from 5.1 V to 40 V. It features internal feed‑forward line regulation, soft‑start, undervoltage lock‑out, thermal shutdown, and current limiting, making it suitable for micro‑processor‑based systems.
This handbook contains the device description, absolute maximum ratings, pin‑out and functions, detailed electrical and DC characteristics, dynamic performance data, reset and power‑fail behavior, and mechanical dimensions. The data are presented with typical test conditions and reference figures for design implementation.
