EBU/EBT are non-polarized aluminum electrolytic capacitors produced by Vishay Roederstein. They are characterized by their small size and low ESR values, and are suitable for use in circuits with varying or unknown polarity.
The EBU and EBT series are non‑polarized aluminum electrolytic capacitors offered by Vishay Roederstein. They are available in axial leaded styles with compact dimensions and are suited for circuits with changing polarity (EBU) or audio‑frequency networks (EBT). The series features low ESR values and a wide frequency range.
The document includes quick reference tables, selection charts, dimensional drawings, packaging information, detailed electrical data, lifetime tables, and temperature‑dependent performance graphs. It also contains a legal disclaimer and contact information for technical support.
| Nominal case size | 8 × 18 mm to 10 × 25 mm |
|---|---|
| Rated voltage (DC) | 6.3 V to 63 V (EBU), 40 V to 100 V (EBT) |
| Rated voltage (AC) | 15 V to 35 V |
| Capacitance tolerance | -10 % to +50 % (EBU), -15 % to +15 % (EBT) |
| Operating temperature range | -40 °C to +85 °C |
The capacitors are rated for temperatures from –40 °C up to +85 °C.
EBU capacitors are offered in 8 × 18 mm, 10 × 18 mm, and 10 × 25 mm case sizes.
