The AM15EW-IZ 15 Watt | DC-DC Converter is a switching power module produced by Aimtec. It features a wide 4:1 input range, adjustable output, low ripple and noise, operating temperature range of -40 to +75ºC, etc.
The AM15EW-IZ series from Aimtec offers 15 W DC‑DC conversion in single‑ and dual‑output versions. Features include RoHS compliance, wide 4:1 input range, low output ripple, remote on/off control, and capacitive loading up to 4500 µF.
Technical data cover input and output specifications, isolation voltage, switching frequency, operating temperature, dimensions, weight, and pin‑out details, along with safety graphs and block diagrams for both output configurations.
| Input voltage range (single output) | 9‑36 V |
|---|---|
| Input voltage range (dual output) | 18‑75 V |
| Output ripple | 80 mV p‑p |
| Isolation voltage rating | 1500 VDC |
| Switching frequency (full load) | 200 kHz |
| Operating temperature range | -40 °C to +75 °C |
| Weight | 33 g |
| MTBF | > 800 000 h |
The single‑output models accept 9‑36 V, while the dual‑output models accept 18‑75 V.
The isolation rating is 1500 VDC.
The device operates from –40 °C to +75 °C without derating.
