The ADuC834 is a complete smart transducer front end, integrating two high resolution ADCs, an 8-bit MCU, and program/data Flash/EE memory on a single chip.
The ADuC834 MicroConverter integrates two high‑resolution ADCs (16‑bit and 24‑bit), an 8052‑compatible MCU core, and on‑chip flash/program memory. It targets intelligent sensor, data‑logging, and precision monitoring applications.
The device operates from 3 V or 5 V supplies, offers up to 26 programmable I/O lines, multiple timers, UART/SPI/I²C interfaces, and on‑chip DACs and temperature sensor, making it a versatile solution for embedded instrumentation.
| Flash program memory | 62 Kbytes |
|---|---|
| Flash data memory | 4 Kbytes |
| Primary ADC resolution | 24‑bit (no missing codes) |
| Normal mode current consumption | 2.3 mA @ 3.6 V |
| Package | 52‑Lead MQFP (14 mm × 14 mm) |
The device is specified for operation at both 3 V and 5 V supplies.
The ADuC834 provides 26 programmable I/O lines.
The ADC conversion rate is 5.4 Hz minimum on both channels.
The flash/EE memory is rated for 100,000 program/erase cycles.
