This manual introduces the basic operation and controls of the Nikon Speedlight flash, including accessories, installation, and usage instructions.
This manual explains how to attach the SB-14 to a camera, connect the sensor unit, and use the various controls such as the shutter‑speed dial, exposure calculator, and sync cords. Detailed diagrams show the bracket, wide‑flash adapter, and flash head adjustments.
Additional sections cover battery performance, optimum operating temperatures, and full specifications including guide number, coverage angle, power source, recycling time, and dimensions. The guide also lists accessories like the DC unit, TTL sensor cord, and sync cord.
| Horizontal coverage angle | 67° (77° with SW‑5) |
|---|---|
| Power source | Battery Pack SD‑7 holding six C‑type batteries |
| Dimensions (H × W × D) | 217 mm × 94 mm × 91 mm |
Insert the bracket mounting pin into the bracket mounting adapter and screw the bracket’s attachment screw into the camera’s tripod socket.
The SB‑14 is powered only by an external power supply that connects to the external power terminal.
Watch the ready‑light; when the LED ready‑light illuminates, the flash is ready for the next shot.
