The document is the technical manual of 74ACTQ08 Quiet Series™ Quad 2-Input AND Gate, which introduces the features and characteristics of the product.
The 74ACTQ08 is a Quiet Series™ quad 2‑input AND gate featuring reduced latch‑up immunity, TTL‑compatible inputs and 24 mA source/sink capability. It utilizes Fairchild Quiet Series™ technology for low noise and improved dynamic threshold performance.
The document provides absolute maximum ratings, recommended operating conditions, detailed DC and AC electrical characteristics, noise test procedures, and physical dimensions for both SOIC and SOP packages.
| Supply Voltage (VEE) | 4.5 V to 5.5 V |
|---|---|
| Input Voltage (VIN) | 0.8 V to 2.0 V |
| Operating Temperature | -40 °C to +85 °C |
| Output Source/Sink Current | 24 mA |
| Input Compatibility | TTL‑compatible |
| Package (SOIC) | 14‑Lead Small Outline IC (M14A) |
The device operates with a supply voltage between 4.5 V and 5.5 V.
The input voltage can vary from 0.8 V to 2.0 V.
Each output can source or sink up to 24 mA.
It is offered in a 14‑lead SOIC (M14A) and a 14‑lead SOP (M14D) package.
