The Bridgelux LS Array Series of LED Array products combine the higher efficacy, lifetime, and reliability benefits of LEDs with the light output levels of many conventional lighting sources.
The LS Array Series offers compact, high‑flux LED arrays designed for general lighting applications such as replacement lamps, decorative lighting, and white‑goods. The series delivers 240‑360 lumens at 4‑8 W thermal limits and includes warm, neutral, and cool white options.
The data sheet includes detailed tables on flux, optical, electrical, and mechanical characteristics, as well as environmental compliance, UL recognition, packaging details, and links to design resources and application notes.
| Typical Luminous Flux (Warm White BXRA-W0240) | 240 lm |
|---|---|
| Forward Voltage (Warm White BXRA-W0240) | 12.1 V |
| Operating Case Temperature | 105 °C |
| LED Junction Temperature (Maximum Rating) | 150 °C |
The maximum operating case temperature is 105 °C.
The series is projected to maintain greater than 70 % of its initial lumen output after 50,000 hours.
The product became UL recognized on 31 March 2010 (file E333389).
