1N4565AUR-1 thru 1N4584AUR-1 are CDI low current temperature compensated zener reference diodes, packaged as DO-213AA with leads, suitable for surface mounting, working current range is 0.5-4.0mA.
The CDLL4565‑CDLL4584A series are surface‑mount, lead‑less Zener reference diodes with low‑current operating ranges from 0.5 mA to 4 mA. They are offered in hermetically sealed DO‑213AA, MELF, SOD‑80, and LL34 packages and are designed for operation from –65 °C to +175 °C.
Key electrical specifications include a reverse leakage current of 2 µA at 25 °C with a 3 V reverse bias, a DC power dissipation of 500 mW at +50 °C, and a power‑derating factor of 4 mW/°C above +50 °C. Temperature coefficient data and Zener impedance curves are provided for design reference.
| Operating Temperature | -65 °C to +175 °C |
|---|---|
| Storage Temperature | -65 °C to +175 °C |
| DC Power Dissipation | 500 mW @ +50 °C |
| Power Derating | 4 mW/°C above +50 °C |
| Reverse Leakage Current | 2 µA @ 25 °C (VR = 3 V) |
They operate from –65 °C up to +175 °C.
The reverse leakage current is 2 µA when the reverse voltage is 3 V.
Each diode can dissipate up to 500 mW at +50 °C.
Power derates at 4 mW per degree Celsius above +50 °C.
