MAX3212 is a low-power serial interface chip using Maxim's Auto-Shutdown mode. It has 3 RS-232 drivers and 5 RS-232 receivers, and works with a power supply of 2.7V to 3.6V. It is compatible with EIA/TIA-232E and V.28/V.24 standards and has a data transmission speed of 235kbps.
The MAX3212 is a low‑power RS‑232 line driver/receiver from Maxim. It provides three drivers and five receivers, operates from 2.7 V to 3.6 V, and maintains true RS‑232 voltage levels across the range. The device includes Maxim’s Auto‑Shutdown feature that reduces supply current to 1 µA when no valid signal is detected.
The transceiver is offered in 28‑pin SO and SSOP packages and guarantees a data rate of 235 kbps. Detailed electrical characteristics, timing specifications, and pin descriptions are provided for designers integrating the part into notebook, palmtop, and battery‑powered equipment.
| Supply current (Auto‑Shutdown) | 1 µA |
|---|---|
| Operating voltage range | 2.7 V to 3.6 V |
| Number of drivers | 3 |
| Number of receivers | 5 |
| Guaranteed data rate | 235 kbps |
| Package types | 28‑pin SO, 28‑pin SSOP |
The MAX3212 draws only 1 µA in Auto‑Shutdown mode.
It provides three RS‑232 drivers and five RS‑232 receivers.
The part is offered in 28‑pin SO and 28‑pin SSOP packages.
The device guarantees a data rate of 235 kbps.
