Omron NT31/NT31C Programmable Terminals Setup Manual

About this manual

This manual explains how to install and operate the Omron NT31 and NT31C programmable terminals. It describes the terminals' functions, system configuration, and the various communication methods with a host controller, including RS‑232C and RS‑422A/485 ports.

The guide also covers system menu operation, memory initialization, maintenance procedures, and troubleshooting steps. Appendices provide specifications, dimensions, cable‑making instructions, and a list of options and models.

What's inside

• Intended Audience
• General and Safety Precautions
• Role and Operation of NT31/NT31C
• System Configuration and Communications
• Hardware Settings and Connections
• Connecting to Host (RS‑232C, RS‑422A/485)
• System Menu Operation
• Troubleshooting and Maintenance
• Specifications and Dimensions
