The ADXL325 is a small, low-power, complete 3-axis accelerometer with signal-conditioned voltage outputs. The product measures acceleration with a minimum full-scale range of ±5 g. It can measure the static acceleration of gravity in tilt-sensing applications, as well as dynamic acceleration, resulting from motion.
The ADXL325 accelerometer provides three‑axis acceleration measurement with signal‑conditioned voltage outputs. It operates from a single supply of 1.8 V to 3.6 V, draws about 350 µA typical current, and fits in a 4 mm × 4 mm × 1.45 mm LFCSP package. Bandwidth for the X and Y axes can be set up to 1.6 kHz, while the Z axis can reach 550 Hz, using a single external capacitor per axis.
The device is rated for ±5 g full‑scale measurement, 10,000 g shock survival, and operates from –40 °C to +85 °C. It includes self‑test pins, low noise density (250 µg/√Hz), and is RoHS/WEEE compliant, making it suitable for mobile, gaming, and health‑monitoring applications.
| Measurement Range | ±5 g |
|---|---|
| Sensitivity (typical) | 174 mV/g (typical) |
| Supply Voltage | 1.8 V to 3.6 V |
| Supply Current | 350 µA (typical at 3 V) |
| Bandwidth (X/Y) | 0.5 Hz – 1.6 kHz (no external filter) |
| Bandwidth (Z) | 0.5 Hz – 550 Hz (no external filter) |
| Noise Density | 250 µg/√Hz rms |
| Temperature Range (operating) | –40 °C to +85 °C |
| Shock Survival | 10,000 g |
The ADXL325 measures acceleration up to ±5 g on each axis.
It operates from a single supply voltage between 1.8 V and 3.6 V.
Typical supply current is 350 µA when powered at 3 V.
Yes, bandwidth is set with a single external capacitor per axis (C_X, C_Y, C_Z).
