This service manual covers the CS-10 synthesizer’s service information, including a full index of sections such as specifications, panel layout, circuit diagrams, wiring diagrams, and adjustment procedures. It contains detailed circuit diagrams for the VCO, VCF, VCA, and REG sections, as well as parts lists and standard inspection guidelines.
The document also lists the instrument’s technical specifications, dimensions, power requirements, and component counts, and provides step‑by‑step adjustment instructions for the VCA and REG sections to ensure proper operation and performance.
| Number of keys | 37 keys (C3 ~ C6, 3 octaves) |
|---|---|
| Power requirements | AC 50/60 Hz, 12 W |
| Dimensions (W × D × H) | 710 mm × 290 mm × 155 mm |
| Weight | ≈ 8 kg |
| Component count | 18 ICs, 17 transistors, 15 diodes |
The CS-10 has 37 keys covering three octaves from C3 to C6.
It requires AC power at 50/60 Hz with a consumption of 12 W.
The instrument measures 710 mm × 290 mm × 155 mm and weighs about 8 kg.
The CS-10 contains 18 integrated circuits, 17 transistors, and 15 diodes.
