The MAX1444 is a 10-bit, 3V analog-to-digital converter (ADC) that features a pipelined 10-stage ADC architecture with fully differential wideband track-and-hold (T/H) input and digital error correction incorporating a fully differential signal path. This ADC is optimized for low- power, high dynamic performance applications in imaging and digital communications.
The MAX1444 is a 10‑bit, 3 V analog‑to‑digital converter featuring a pipelined 10‑stage architecture, fully differential track‑and‑hold input, and digital error correction. It operates from a single 2.7 V to 3.6 V supply and consumes only 57 mW in normal mode, delivering 59.5 dB SNR at a 20 MHz input frequency. The device includes an internal 2.048 V bandgap reference and offers flexible reference options for higher accuracy.
The ADC is supplied in a 5 mm × 5 mm 32‑pin TQFP package and is specified for an industrial temperature range of –40 °C to +85 °C. Electrical characteristics such as a 400 MHz –3 dB input bandwidth, 74 dBc SFDR at 20 MHz, and low‑power shutdown mode (5 µA) are provided, along with detailed timing, pin configuration, and package drawings.
| Supply Voltage (Vop) | 2.7 V to 3.6 V |
|---|---|
| Power Consumption (Normal Operation) | 19 mA |
| Shutdown Current | 5 µA |
| Signal‑to‑Noise Ratio (SNR) | 59.5 dB at 20 MHz |
| Spurious‑Free Dynamic Range (SFDR) | 74 dBc at 20 MHz |
| Input Bandwidth (‑3 dB) | 400 MHz |
| Package | 32‑pin TQFP, 5 mm × 5 mm |
| Resolution | 10 bits |
The MAX1444 operates from 2.7 V to 3.6 V.
The device is specified for up to 40 Msps (4OMsps).
It achieves a signal‑to‑noise ratio of 59.5 dB at 20 MHz.
The ADC is offered in a 32‑pin TQFP package measuring 5 mm × 5 mm.
