This product is a BenQ projection system with SVGA resolution, 2000 ANSI lumens brightness, 2500:1 contrast ratio, 4:3 and 16:9 optional aspect ratio, manual zoom 1.10:1, and can project 30 inches to 300 inches.
The BenQ MP514 is a SVGA native resolution projector offering 2000 ANSI lumens brightness, 2500:1 contrast ratio, and a range of picture modes including BrilliantColor™ and wall‑color correction. It features a 4000‑hour lamp life in Eco mode, manual zoom (1.10:1), and a throw ratio of 1.97‑2.16, making it suitable for various presentation environments.
This manual covers all aspects of installation and operation: lamp care, input and output connections (PC analog RGB, component video, composite video, RS‑232), dimensions and weight, power requirements, on‑screen display languages, picture mode settings, and optional accessories such as ceiling mounting kits and spare lamps.
| Native Resolution | SVGA (800 x 600) |
|---|---|
| Brightness | 2000 ANSI lumens |
| Contrast Ratio | 2500:1 (Full on/Full off) |
| Lamp Life (Eco mode) | 4000 Hours |
| Lamp Power | 180W, 3500/4000 hours (Normal/Economic mode) |
| Zoom Ratio | Manual Zoom, 1.10:1 |
| Throw Ratio | 1.97 - 2.16 |
| Dimensions (W x H x D) | 273 x 108 x 215 mm |
| Weight | 2.4 kg (5.3 lbs) |
| Audible Noise | 33/30 dB (Normal/Economic mode) |
The MP514 has a native SVGA resolution of 800 × 600 pixels.
It delivers 2000 ANSI lumens of brightness.
The lamp is rated for 4000 hours when used in Eco mode.
