ViewSonic PJ513DB is a lightweight and portable DLP projector that weighs just 5.7 pounds and produces 2,200 lumens. It is the right choice for small offices, classrooms and even home use. With DLP® technology and BrilliantColor™ technology, PJ513DB delivers amazingly clear images. The projector supports 720p and 1080i signals, and it can connect with PC, DVD player and more, providing versatile and dynamic presentations. PJ513DB has 800x600 SVGA native resolution, digital keystone correction and zoom lens, ensuring the best possible image in virtually any setting. PJ513DB DLP® projector delivers excellent performance and value for business and education markets.
The PJ513DB is a lightweight (5.7 lb) DLP® projector designed for small offices, classrooms, and home use. It offers 2,200 ANSI lumens brightness, BrilliantColor™ technology, and multiple picture modes for versatile presentations. The projector supports HD signals (720p, 1080i) and includes on-screen controls for geometry, color, and lamp management.
The manual covers optional accessories, detailed technical specifications, installation guidelines, and warranty information. It also lists input connectors, power requirements, environmental operating ranges, and dimensions to help users set up the projector quickly and maintain it effectively.
| Brightness (max) | 2,200 ANSI lumens |
|---|---|
| Contrast Ratio | 2000:1 |
| Resolution | 800x600 SVGA (native) |
| Lamp Life (eco‑mode) | up to 3,000 hrs |
| Weight (net) | 5.7 lb (2.6 kg) |
| Dimensions (W × H × D) | 10.3" × 4.2" × 8.6" (263 mm × 218 mm × 108 mm) |
| Throw Ratio | 1.8‑1.98:1 |
| Power Consumption (typical) | 260 W |
| Input Signals | Computer and Video RGB analog, NTSC, PAL, SECAM, HDTV (480p, 720p, 1080i) |
Eco‑mode can extend the lamp life up to 3,000 hours.
The projector delivers a maximum brightness of 2,200 ANSI lumens.
It measures 10.3" × 4.2" × 8.6" (263 mm × 218 mm × 108 mm).
