ViewSonic VA2010wb is a high-value 20-inch widescreen LCD monitor with 5ms video response and 1680 x 1050 high resolution. It is perfect for home/small office users, gamers and video application users.
The ViewSonic VA2010wb is a 20‑inch widescreen LCD monitor with a native 1680 × 1050 resolution, 1000:1 contrast ratio and a fast 5 ms video response time. It offers both analogue VGA and digital DVI‑D inputs, a slim‑bezel design and ergonomic tilt adjustment.
The manual includes detailed specifications, connection diagrams, power and environmental information, as well as warranty and regulatory compliance details. It also provides quick‑start guidance for connecting the monitor to PC or Mac systems.
| Native resolution | 1680 × 1050 @ 60 Hz |
|---|---|
| Contrast ratio | 1000:1 (typ) |
| Brightness | 300 cd/m² (typ) |
| Response time | 5 ms (video) |
| Viewing angles | 160° H / 160° V (10:1) |
| Power consumption | 39 W typical, <1 W in power‑save |
| Dimensions (with stand) | 481 mm × 399 mm × 155 mm |
| Weight (with stand) | 4.9 kg net |
| Analogue input connector | 15‑pin mini D‑Sub (detachable cable) |
| Digital input connector | 24‑pin DVI‑D (detachable cable) |
The monitor’s native resolution is 1680 × 1050 at 60 Hz.
It includes an analogue 15‑pin mini D‑Sub connector and a digital 24‑pin DVI‑D connector.
Typical power consumption is 39 W, dropping to less than 1 W in power‑save mode.
With the stand, the monitor measures 481 mm × 399 mm × 155 mm.
