A repair reference guide for Hisense color televisions, covering circuit diagrams, IC data, I2C bus debugging, and LCD TV troubleshooting.
This manual provides on‑site repair and troubleshooting information for Hisense color televisions, aimed at service technicians. It compiles the latest repair data for Hisense super‑single‑chip, HD series, and LCD TVs.
The book is divided into three parts: the upper section classifies circuits and lists major ICs with pin voltage data, the middle section explains TC/I2C bus debugging methods, and the lower section presents LCD TV signal flow, main IC functions, and includes an appendix with an integrated‑circuit index. This manual is written in Chinese.
| Backlight setting (0‑20 lux) | 220 |
|---|---|
| Backlight setting (20‑100 lux) | 120 |
| EMI parameter setting | 4 |
It covers Hisense super‑single‑chip color TVs, HD series color TVs, and LCD TVs.
The manual is divided into three parts: upper (circuit classification), middle (TC bus debugging), and lower (LCD TV signal flow and IC functions).
Yes, an appendix provides an integrated‑circuit index.
