This is an ESD safe digital soldering station with multiple functions, which can be configured independently and differently with the above mentioned functions.
The ERSA DIGITAL 2000 A is an intelligent soldering station that automatically identifies connected tools – such as the Tech, Micro, Power, Pincette 40, and X‑Tool desoldering irons – and adjusts settings accordingly. It offers flexible temperature control (°C/°F), standby periods, offset and calibration functions, and a password lock for safety.
Technical data include an 80 W power rating, 230 V supply, 24 V secondary voltage, temperature range 50‑450 °C, digital PID temperature control, antistatic design, and a digital display. The station uses ERSADUR long‑life tips with a 0.4 mm diameter and supports replacement heating elements and irons.
| Power rating | 80 W |
|---|---|
| Supply voltage | 230 V |
| Secondary voltage | 24 V |
| Temperature range | 50-450 °C |
| Coating tip | ERSADUR Long Life tip |
| Antistatic design | Yes |
| Digital display | Yes |
| Soldering tip shape | pencil point |
| Soldering tip diameter | 0.4 mm |
| Replacement iron model | 0270BDJ |
| Soldering/Desoldering tip number | 212 |
| Replacement heating element | 021100J |
It can operate soldering irons Tech tool, Micro tool, Power tool, Pincette 40 desoldering tweezers and X‑Tool desoldering iron.
The temperature is controlled by a digital PID algorithm optimized for precise and quick temperature control.
Yes, the ERSA DIGITAL 2000 A is fully antistatic according to MIL‑SPEC/ESA standards.
Yes, the unit can be switched between °C and °F on the temperature display.
