Both the WD1 and WD2 stations feature three independent and fully programmable preset buttons that allow you to select a preset temperature for each. The operation of the buttons is similar to the station selection buttons on a car radio. Just set the temperature to the desired setting, press and hold any of the buttons for two seconds, and that button is preset to that temperature. The programming range of the buttons is anywhere within the station’s temperature range of 150°F to 850°F. A button can be preset to your favorite idle temperature, allowing you to instantly activate a feature that saves both tip life and power, even before the station activates it automatically.
The WD1 and WD2 stations provide big‑screen simplicity with a 67 mm × 29 mm high‑contrast LCD that shows current temperature and preset values. Three independent programmable preset buttons let users store frequently used temperatures, and the stations support a range of 150 °F – 850 °F.
Both models are available with micro‑soldering pencils (WP80 80 W, WMP 65 W) and optional pencil stands. Power units come in single‑ or dual‑channel configurations, offering input voltage 120 V, output 24 V, and compact footprints suitable for workstation integration.
| Power consumption (WP80 pencil) | 80 W |
|---|---|
| Voltage (pencil) | 24 V |
| Cord length (pencil) | 4 ft (1.22 m) |
| Temperature range (station) | 150 °F – 850 °F (50 °C – 450 °C) |
| Footprint (power unit) | 5.27" × 4.25" × 6.77" (134 × 108 × 147 mm) |
| Temperature accuracy | +0 °F (45 °C) |
| Temperature stability | +10 °F (+6 °C) |
Each station has three independent programmable preset buttons.
The stations operate from 150 °F to 850 °F.
The power unit accepts 120 V input and provides a 24 V output.
The WP80 pencil consumes 80 W of power.
