Fluke 321 and 322 are designed to verify the presence of load current, ac voltage and continuity of circuits, switches, fuses and contacts. These small and rugged clamp meters are ideally suited for current measurements up to 400 A in tight cable compartments. Model 322 also offers DC voltage measurements and has a higher resolution for loads below 40 A.
The Fluke 321 and 322 clamp meters are compact, rugged devices intended to verify load current, AC voltage, and continuity of circuits, switches, fuses and contacts. They are suited for current measurements up to 400 A in tight cable compartments, with the 322 model also offering DC voltage measurement and higher resolution for low‑current loads.
The manual lists key specifications such as a 190 mm × 63 mm × 35 mm size, 0.23 kg weight, 25 mm jaw opening, and a typical battery life of 100 hours using two AAA carbon‑zinc cells. Included accessories are a soft carrying case, test leads, AA batteries, a coated instruction card, and a safety information sheet, and the product carries a two‑year warranty.
| Current AC range | 0‑400 A |
|---|---|
| Current AC resolution | 0.1 A |
| Voltage AC range | 0‑400 V |
| Voltage AC resolution | 0.1 V |
| Voltage DC range | 0‑400 V |
| Voltage DC resolution | 0.1 V |
| Resistance range | 0‑400 Ω |
| Resistance resolution | 0.1 Ω |
| Continuity limit | ≤ 30 Ω |
| Jaw opening | 25 mm |
| Size (HxWxD) | 190 mm × 63 mm × 35 mm |
| Weight | 0.23 kg |
| Battery life | 100 hours (typical) |
It can measure up to 400 A of AC current.
Yes, the 322 model offers DC voltage measurement.
The battery life is about 100 hours with two AAA carbon‑zinc cells.
A soft carrying case, test leads, two AA alkaline batteries, a coated instruction card, and a safety information sheet are included.
