The OP‑42 is a fast, precision JFET‑input operational amplifier offering a 58 V/µs slew rate, 10 MHz gain‑bandwidth product, and low offset voltage. It is internally compensated for unity‑gain operation and consumes less than 6 mA supply current, making it suitable for high‑speed DAC output stages and sample‑and‑hold circuits.
The device is available in multiple packages (TO‑99, 8‑Pin Hermetic DIP, 8‑Pin Plastic DIP, 20‑Contact LCC, 8‑Pin SO) and meets stringent radiation‑hardness requirements for military and aerospace applications. Detailed electrical characteristics, typical performance curves, and ordering information are provided.
| Slew Rate | 58 V/µs |
|---|---|
| Gain‑Bandwidth Product | 10 MHz (typ) |
| Input Offset Voltage | 750 µV max |
| Input Bias Current | 200 pA max |
| Supply Current | 5.1 mA (typ) |
The OP‑42 has a typical slew rate of 58 V/µs.
The input offset voltage is specified as 750 µV maximum (typical values 0.4‑1.6 mV in the detailed tables).
