This is a user manual for the Samsung ML-2510 Series/ML-2570 Series Monochrome Laser Printer. The manual describes the features and characteristics of the printer, as well as how to use it.
This manual provides detailed instructions for installing, configuring and using Samsung's ML-2510 and ML-2570 series monochrome laser printers. It includes safety precautions, basic setup, software installation, network configuration, media loading, printing procedures and troubleshooting tips.
The guide also lists technical specifications such as printing speed, resolution, power consumption, noise levels and recommended operating environment, helping users achieve optimal performance and maintain the printer over its service life.
| Printing speed | Up to 24 ppm A4 (25 ppm Letter) |
|---|---|
| Resolution | ML-2510: 1200 × 600 dpi, ML-2570/ML-2571N: 1200 × 1200 dpi |
| Warm‑up time | Less than 15 seconds |
| First print‑out time | 9 seconds (from Ready) |
| Power rating | 110‑127 VAC, 5.5 A (ML‑2510) / 220‑240 VAC, 3 A (ML‑2570/ML‑2571N) |
| Power consumption (normal mode) | 390 W (ML‑2510) / 400 W (ML‑2570, ML‑2571N) |
| Power‑save mode consumption | Less than 6.5 W (ML‑2510) / 8.5 W (ML‑2570, ML‑2571N) |
| Noise level (standby) | Less than 35 dB |
| Noise level (printing) | Less than 53 dBA |
| Toner cartridge life | 3,000 pages at 5 % coverage (ISO 19752) |
| Monthly duty cycle | Up to 10,000 pages |
| Weight | 8.9 kg (including consumables) |
| Dimensions (W × D × H) | 13.9 × 11.7 × 9.7 inches (354 × 297 × 246 mm) |
| Operating temperature | 50 °F – 90 °F (10 °C – 32 °C) |
| Operating humidity | 20 % – 80 % RH |
| Printer language support | SPL, PostScript 3, PCL 6 |
| Memory | ML‑2510: 8 MB (non‑expandable); ML‑2570/ML‑2571N: 32 MB (non‑expandable) |
The printers can print up to 24 pages per minute on A4 paper and up to 25 pages per minute on Letter size.
Average power consumption is 390 W for the ML‑2510 and 400 W for the ML‑2570 and ML‑2571N models.
The printer warms up in less than 15 seconds.
The recommended operating temperature is 50 °F to 90 °F (10 °C to 32 °C).
