42-inch wide XGA plasma public display is a state-of-the-art, cost-effective plasma monitor specially designed for indoor public display applications. The high class scaler, advanced digital video processing and the latest plasma technology guarantee optimal display of your message.
The Philips BDH4241V is a 42" XGA plasma monitor designed for indoor public display applications. It offers HD‑ready picture quality, motion‑compensated deinterlacing, picture‑in‑picture, and fanless operation for reliable 24/7 use.
The manual covers display specifications, supported video formats, connectivity options (DVI‑D, RS232, VGA, component, composite, S‑video, SCART, audio RCA), remote network control via RS232, installation accessories, and power and environmental requirements.
| Panel size | 42" / 106.7 cm |
|---|---|
| Aspect ratio | 16:9 |
| Panel resolution | 1024 x 768 |
| Brightness | 1000 cd/m² |
| Contrast ratio (typical) | 5000:1 |
| Power consumption (typical) | 300 W |
| Power supply | 100‑240 VAC, 50/60 Hz |
| Dimensions (without base) | 1028 × 625 × 89.8 mm |
| Weight | 31 kg |
| Panel lifetime (50% brightness) | 60 000 h |
The monitor is network controllable via the RS232 protocol.
The typical power consumption is 300 W.
The panel lifetime is expected to exceed 60 000 hours before brightness falls to 50% of its initial value.
