This file introduces Weller brand multi-function digital desoldering and rework stations, including WMD 3, WMD 1A, WMD 1D, WDD 161V, WDD 81V and WAD 101.
The document presents Cooper's Weller line of desoldering and rework stations, including the WMD 3, WMD 1A, WMD 1D, WDD 161V, WDD 81V, and the hot‑air station WAD 101. Each station is described with its features, optional accessories, and a matrix that helps users select compatible tools.
Technical data for each model is provided, covering dimensions, power input, voltage, safety class, and performance parameters such as temperature ranges and pump pressure. Safety rests with Stop+Go functions and calibration options are also detailed.
| Dimensions (WMD 3) | 240 x 270 x 105 mm (W x D x H) |
|---|---|
| Line Voltage (WMD 3) | 230 V 50 Hz |
| Power Input (WMD 3) | 310 W |
| Safety Class (WMD 3) | 1 and 3 |
| Pump Max Low Pressure | 0.7 bar |
| Hot‑air Pencil Temperature Range | 50 °C – 550 °C |
| Soldering/Desoldering Iron Temperature Range | 50 °C – 450 °C (150 °C – 550 °C for WSP 150) |
The WMD 3 can operate a soldering iron, a desoldering iron, and a hot‑air pencil at the same time, each controlled by its own micro‑processor channel.
The built‑in pump can generate a maximum low pressure of 0.7 bar and convey vacuum for up to 20 minutes.
Yes, all stations have an antistatic coating on the housing that meets ESD safety specifications.
