The manual begins with safety precautions, warning symbols, and proper installation guidelines to ensure safe use of the front‑load washing machine. It also explains how to connect power, water supply, and drainage hoses.
Subsequent sections describe the control panel functions, detergent and softener usage, various wash programs (cotton, quick, wool, etc.), capacity limits, cycle times, and troubleshooting tips for common issues such as drainage problems or error indicators. This manual is written in Chinese.
| Rated Voltage | 220 V AC |
|---|---|
| Rated Frequency | 50 Hz |
| Maximum Power Consumption | 1920 W |
| Power Consumption (Spin) | 800 W |
| Heating Power | 1555 W |
| Dimensions (W×D×H) | 690×625×1016 mm |
| Net Weight | 87 kg |
| Wash Capacity | 6 kg |
| Spin Capacity | 6 kg |
| Standard Water Consumption | 20 L |
| Standard Water Usage | 66 L |
| Water Pressure | 0.03‑1 MPa |
Press the lock key for about 5 seconds to lock or unlock the child safety lock.
Remove the detergent drawer and rinse it with water; if residue remains, use a cup of water to flush it out.
