This document introduces different models of Samsung digital camcorders and their usage instructions, including safety precautions, function settings, storage media, and accessory design specifications.
This manual provides safety warnings, component identification, and step‑by‑step operating instructions for Samsung SMX‑F50, SMX‑F53, SMX‑F54, SMX‑F500 and SMX‑F530 digital camcorders. It explains how to set up the camera, use the battery and power adapter, select storage media, and adjust recording settings.
The guide also includes detailed menu navigation, connection to TV displays, USB data transfer to a computer, and a troubleshooting section for common issues. Technical specifications are listed at the end of the document. This manual is written in Chinese.
| Video System | PAL |
|---|---|
| Video Compression Format | H.264/AVC |
| Audio Compression Format | AAC |
| Effective Pixels | 740K |
| Maximum Pixels | 800K |
| Lens | F1.8‑4.9, 52x optical, 65x Intelli, 2200x digital |
| LCD Screen | 2.7‑inch widescreen |
| Power Supply (Adapter) | 5.0 V |
| Power Consumption | 1.7 W (standby) / 2.0 W (LCD on) |
| Operating Temperature | 32 °F – 104 °F (0 °C – 40 °C) |
| Dimensions (W×H×D) | 2.05" × 2.3" × 4.43" (53.9 mm × 56.4 mm × 119.0 mm) |
| Weight | ≈220 g |
The SMX‑F50, SMX‑F500 and SMX‑F530 models have no built‑in memory and require a storage card.
It records video in H.264 (MPEG‑4 Part 10/AVC) format.
Use the TV output settings; the manual provides a section titled “连接到电视 (16:9/4:3)”.
